| DIMENSION | ||
| T | 12 | Number of pinion Teeth |
| D | 59.5 | Drive O.D.(mm) |
| G | 56 | Pinion O.D(mm) |
| ID | 14.3 | Pinion I.D.(mm) |
| L | 83 | Lenght(mm) |
| SPL | 10 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 6033AD0129 6033AD4243 3099583 33099583 233722 54-91157 |
Volvo:FM1998 |
