| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 60 | Drive O.D.(mm) |
| G | 34.8 | Pinion O.D(mm) |
| ID | 14.3 | Pinion I.D.(mm) |
| L | 77.5 | Lenght(mm) |
| SPL | 6 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 79081045 7984505 9961787 SD077 132821 54-9307 |
Alfa Romeo:30AR8,32AR8,35AR8,40AR8 Fiat:131,132,Argenta,Nuova Argenta Fiat Allis:4 Apripista Fiat Iveco:Caminhão,Daily,Ducato Seat:131 |
