| DIMENSION | ||
| T | 10 | Number of pinion Teeth |
| D | 48 | Drive O.D.(mm) |
| G | 27.2 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 78 | Lenght(mm) |
| SPL | 9 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 105332 105325 SD804 132200 |
Peugeot:504 |
