| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 46.6 | Drive O.D.(mm) |
| G | 25.8 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 80.5 | Lenght(mm) |
| SPL | 3 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 1987BE0000 DR1902 DR1905 223102 1108481 1875687 1935827 1935829 1945842 1947727 1954842 1954867 1965538 1965723 1965923 D2008 D2014 D2020 D2049 10456422 |
General Motors/Chevrolet 400 Buick C20 Opala 4 e 6 cil Silverado gasolina Willys Jeep 1969...1971 |
