| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 52.6 | Drive O.D.(mm) |
| G | 29.2 | Pinion O.D(mm) |
| ID | 14 | Pinion I.D.(mm) |
| L | 70.5 | Lenght(mm) |
| SPL | 6 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 00-41-29 | Fiat |
Recommended Products
Warmly welcome your arrival. We will povide best products and best after-sales service for you.If you have any questions, please contact us
TQS-165
DIMENSION T 8 Number of pinion Teeth D 45 Drive O.D.(mm) G 24.8 Pinion O.D(mm) ID 12.1 Pinion I.D.(m
TQS-161
DIMENSION T 8 Number of pinion Teeth D 41.5 Drive O.D.(mm) G 28 Pinion O.D(mm) ID 12.1 Pinion I.D.(m
TQS-160
DIMENSION T 8 Number of pinion Teeth D 41.5 Drive O.D.(mm) G 28 Pinion O.D(mm) ID 11 Pinion I.D.(mm)
TQS-159
DIMENSION T 10 Number of pinion Teeth D 60 Drive O.D.(mm) G 40 Pinion O.D(mm) ID 14.3 Pinion I.D.(mm
TQS-158
DIMENSION T 10 Number of pinion Teeth D 41.6 Drive O.D.(mm) G 27.7 Pinion O.D(mm) ID 12.1 Pinion I.D
TQS-157
DIMENSION T 8 Number of pinion Teeth D 41.6 Drive O.D.(mm) G 28 Pinion O.D(mm) ID 12.1 Pinion I.D.(m
