| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 46 | Drive O.D.(mm) |
| G | 25 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 40 | Lenght(mm) |
| SPL | 8 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 93740780N 10524174 |
USED FOR:CHEVROLET AND DAEWOO General Motors/ Chevrolet:Agile 1.4, Celta 1.0, Classic 1.0, Cobalt 1.4 e 1.8,Cruze 1.8, Montana 1.4 |
