| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 46.6 | Drive O.D.(mm) |
| G | 25.8 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 46.6 | Lenght(mm) |
| SPL | 6 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 6471 6491 6493 6494 10452348 10455504 10501804 10504515 10521484 8000045 8000058 89017523 9000876 9000881 9000896 9000901 9000933 9000939 9000948 9000977 333938 54-173 |
Buick: Century Cadillac:Escalade Fiat:Doblo,Idea,Palio,Punto,Stilo,Strada,General Motors/Chevrolet:Astra,Avalanche,Blazer,Celta Isuzu:Ascender Opel:Astra,Signum,Speedster,Vectra,Zafira Oldsmobile:Alero,Silhouette |
