| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 43 | Drive O.D.(mm) |
| G | 25.8 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 64 | Lenght(mm) |
| SPL | 6 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 1987BE0051 136342 233950 6401 6432 6433 223333 10472809 10497257 54-152 |
Daewoo:Lanos,Le Mans,Nexia,Racer General Motors/Chevrolet:Saturno 91 Opel:Astra,Corsa,Vectra UW1036 |
