| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 43.5 | Drive O.D.(mm) |
| G | 25.8 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 45 | Lenght(mm) |
| SPL | 6 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 1987BE0021 6445 6481 TDB974 223294 10451980 10475974 |
Daewoo:Cielo,Espero,Espero CD,Racer General Motors/Chevrolet:Astra,Blazer,Lanos Opel:Vectra CD UW1364 Gear step, notch D-201 |
