| DIMENSION | ||
| T | 8 | Number of pinion Teeth |
| D | 45 | Drive O.D.(mm) |
| G | 28.2 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 56 | Lenght(mm) |
| SPL | 4 | Number of Splines |
| ROTATION | CW | |
| APPLICATION |
| Similar to D-102 (Broach SPL=8) 12019 |
