| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 60 | Drive O.D.(mm) |
| G | 34.8 | Pinion O.D(mm) |
| ID | 14.3 | Pinion I.D.(mm) |
| L | 91 | Lenght(mm) |
| SPL | 10 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 2006209426 F000AL1899 79033659 9817920 9959572 SD314 17092 17184 18030 18033 19024527 |
Fiat: Fiat Allis: New Holland: Trator 8830, Trator DT8630, Trator FNH8430 |
