| DIMENSION | ||
| T | 9 | Number of pinion Teeth |
| D | 46.6 | Drive O.D.(mm) |
| G | 25.8 | Pinion O.D(mm) |
| ID | 12 | Pinion I.D.(mm) |
| L | 64 | Lenght(mm) |
| SPL | 10 | Number of Splines |
| ROTATION | CW | |
| REF NO | APPLICATION |
| 1006209400 1006209405 1006209412 1006209417 9001082750 SD454 TMB421 052911335 056911335 056911335A ZBA911335 3-413 |
Audi:Fox 100,50,80 BMW:528l,728l Ford:Capri 2.8, Granada 2.8,Pampa 1.6 Opel:Ascona,Manta, Rekord D Volkswagen:Golf, Jetta,Passat,Polo,Dasher, Scirocco,Rabbit |
